Belly pan bling

48 posts · Started by bic_bicknell · 06 Aug 2013

Archived topic · Replies closedJump to last post ↓

Post 1 by bic_bicknell,

#1
Here's my just arrived carbon bellypan. I got Skidmarks to lay up a carbon one instead of the usual GRP version.

Seems like it needs a bit of work to get it fitted, you need to drill all the holes and also it's made for the bike without a side-stand so I need to see whether this is possible to retain the stand. Seem to remember that Klinky has done this on his old bike.

Fairly good quality carbon, but not up to Akrapovic standards. Quite a few little air pockets where the first gel coat is missing but I'll just fill them with chemical metal before I matt it all down to fit with the rest of the bike.

Post 2 by MADDOG53,

#2
I like it,,,,to much to ship stateside though,,,,,you'll get it to work I'm sure,,,,

Post 3 by Colonel_Klinck,

#3
You'll need thermal protection in there Bic or you are going to have serious melting issues. You can dremel a section out to make it work with side stand. I used washers to shim the side stand bracket out a bit to give some extra clearance for the side stand as well.

Post 4 by bic_bicknell,

#4
They did supply a load of heat shielding but it's pretty thin stuff. I was going to see if I can get some pucker stuff from internet. The other option is to cut away the close sections of belly pan - I'm not fitting it to act as a race/oil catcher so not bothered if there's holes in the bottom.

Post 5 by No. 47,

#5
Replicast, not Skidmarx?

Post 6 by bic_bicknell,

#6
Well, that's what is interesting. I order the bodywork from the Replicast website and also spoke to a few people there about the order and the delay in getting it to me.

When it turns up there are two photocopied A4 sheets in with the package of brackets and bolts. One of them is a page with three black and white photos on showing where each of the brackets attaches to the bike. The other one is a headed letter which explains how to apply the heat shield. Name on the letter head is Skidmarks with a Weymouth address.

So which company have I actually done business with?

Post 7 by Colonel_Klinck,

#7
Skidmarx do one too. I only know this as I rang them and they confirmed they do a race bellypan. Not on their website though.

Post 8 by Colonel_Klinck,

#8
Post missing

This post could not be recovered from the original forum.

Post 10 by Colonel_Klinck,

#10
That isn't a race pan though. They told me on the phone they definitely did a race version.

Post 11 by No. 47,

#11
Probably the Replicast one then, hence Bic's.

Post 12 by Colonel_Klinck,

#12
Rang Replicast the other day and ordered new fixing kit as part of mine broke. This arrived today. Think this puts it to bed. Skidmarx are making the belly pan for Replicast.


Post 13 by No. 47,

#13
Completely different fixings to my Replicast.................................

Post 14 by bic_bicknell,

#14
That's exactly the same kit and photocopy I got with my "Replicast" belly pan.

So yes, there's something going on here - must be some sort of mould sharing arrangement I'd have thought so that both companies can make money using the same tools. After all the mould must have cost a bit to produce and they probably didn't sell that many really - not even in the good old Superduke Battle days - not enough to make it financially viable/break even anyway.

Anyway, I don't care who makes it as long as it is good quality and fits.

Post 15 by bic_bicknell,

#15
Here's the bike with the Replicast carbon bellypan fitted. All carbon now matted down to the same finish. Looks much better IMO! Easier to mend when I crash and smash bodywork - which happens all the time as it's a working machine and gets used a lot, not just for playing.

Had to reposition the Steibel horn compressor as the bellypan has less room inside than the OE belly.

Modified cut out and attachment holes to allow the sidestand to be fitted.

Cut outs to allow the R&G crash bobbins to be fitted.

No reflections anymore.

Looks good with leather seat material.

Post 16 by Colonel_Klinck,

#16
Nice Bic. She's looking very stealthy.

Post 17 by Ducati Pete,

#17
That looks fantastic.


Post 18 by shadowman,

#18
Post missing

This post could not be recovered from the original forum.

Post 19 by BassAgent,

#19
I'm legitimately feeling like making my bike all black now lol. That looks so good

Post 20 by Grendel,

#20
Post missing

This post could not be recovered from the original forum.

Post 21 by DribbleDuke,

#21
WOW, simply the nicest SD look I've seen. I'm not much the blingologist and most bling sings too loud. You have created a case for untold amounts of non-discretionary drachma and or the pouring of a plethora of poundage into the pit we all call the Superduke and no-one has succeeded as successful.
Fuckorange

Post 22 by cdlabate,

#22
Very nice! Are you going to black out he valve covers and engine mounts?

Post 23 by cdlabate,

#23
Post missing

This post could not be recovered from the original forum.

Post 24 by omky756,

#24
Great job Bic..!!!!
I really think the,satin finish
sets off the carbon fiber..
I'm curious if the leather seat
cover is more comfortable...
I need the carbon SDR tail and seat
base from Adam yet to be all black..
Great look.!!!!

Post 25 by MADDOG53,

#25
Awesome,,awesome ,,awesome neat job doing the kickstand mod to the pan,,,dremel tool super nice,,

Post 26 by bic_bicknell,

#26
Im waiting for some black engine hangers i bought on e bay. Where are they Klinky!

Post 27 by charger,

#27
That is positively evil. Love it.

Post 28 by bic_bicknell,

#28
I have been toying with the idea of painting on Flying Tiger sharks teeth. It's been done before - on other bikes - but it really suits the SD. Amy keeps telling me to "Grow up!'

This is just a photoshop look to see. Opinions please

Post 29 by Colonel_Klinck,

#29
Post missing

This post could not be recovered from the original forum.

Post 30 by bic_bicknell,

#30
No rush! Really, whenever you get round to it. I owe you one anyway for that favour the other week. Anyway, I have this strange feeling that the '06 hangers are maybe different to my '07 ones? Mainly because when I was fitting the Replicast bellypan, I didn't need the cylindrical spacers as they showed on the instructions - and the picture looks different to my hangers. We'll see.

Post 31 by omky756,

#31
[quote="bic_bicknell"]I have been toying with the idea of painting on Flying Tiger sharks teeth. It's been done before - on other bikes - but it really suits the SD. Amy keeps telling me to "Grow up!'

This is just a photoshop look to see. Opinions please

A lot of us are a bit older and ride Superdukes
because they keep us young at heart....
Grow up.???
I agree with ya Bic..
Looks great on the S.D..
Go for it.!!!!

Post 32 by Thom,

#32
Post missing

This post could not be recovered from the original forum.

Post 33 by ktmguy,

#33
Post missing

This post could not be recovered from the original forum.

Post 34 by MADDOG53,

#34
Yes that exhaust,,,,,stick's out now,,,,,,how about covering them with C.F. 2RT has some covers,,,,but I know you could make some,,,your as old as you feel,,,I like teeth,,

http://www.2rteam.fr/2RTeam/2RTeam.uk_f ... erduke.pdf

Post 35 by nampus,

#35
Post missing

This post could not be recovered from the original forum.

Post 36 by Sabre,

#36
Post missing

This post could not be recovered from the original forum.

Post 37 by DribbleDuke,

#37
Bad Ass Bic

Black paint the sub frame.

You can take a hack saw to the buddy peg bosses, but don't take them off complete ly like I did before I had the solo seat to look how it mounted.

You need the top boss mounting hole for your solo seat to mount.

Oh! I painted my sub frame fookin orange.

B B B Baadddd....

Post 38 by lawman,

#38
Nix the cartoons pal...

BBB Bad...

Too much of that retro going on...this bike is beyond that shit.

Post 39 by 41KS,

#39
Ditto on the don't do.

Post 40 by Colonel_Klinck,

#40
Love the matt

In my opinion, eave the engine, it looks great as it is, you have achieved a really nice balance, too much black and it would look vulgar

I think the spring reminds of the KTM blood in a subtle way

good job!

Post 41 by cdlabate,

#41
Post missing

This post could not be recovered from the original forum.

Post 42 by Mac_Boarder,

#42
Took these photos this past weekend on the Rat Dog Dual Sport ride in Tillamook Oregon. Blimp hanger from WWII.






SWING I'd run way too

Post 43 by Mick75,

#43
I think they look best on the Warthog


Post 44 by wizzzard,

#44
Post missing

This post could not be recovered from the original forum.

Post 45 by Johno,

#45
What about the sharks teeth on the belly pan ? Would look cool I reckon ....

Post 46 by Viking,

#46
Other options I think would look ok , a smaller version on the headlight cowl and/or tone down the white of the teeth and eyes to a shade of grey similar to the engine or exhaust to create a bit of balance
Tone down the whole scheme to match the matt black.

Bottom line for any bike decoration is its all in the eye of the beholder. Some will like it, some won't. The important thing is if you like it, do it. Assuming you are using vinyl graphics, worse case scenario you can rip em off if they turn out pox.

Post 47 by Johno,

#47
very nice

Post 48 by Duke4Dirk,

#48
The bike is bad-ass, the stately home is bad-ass. All in all... bad-ass dude!




Oh yeah, I like the little horsey's on the gate.... I was gonna put this above my gate.... Still may.... Not as fancy as the little horsey's but it would make a statement.
